UK US EU AU Plug AC DC Power Adapter 5V 6V 9V 11V 12V 15V 24V 200mA 300mA
Output ratings
| Outout(V) | Ouptput(A) | Power | DOE VI |
| 9V | 200mA | 1.8W | YES |
| 9V | 300mA | 2.7W | YES |
| 9V | 400mA | 3.6W | YES |
| 9V | 500mA | 4.5W | YES |
| 12V | 200mA | 2.4W | YES |
| 12V | 500mA | 6.0W | YES |
Features
1, Small sizedLight weight, compact easy for carrying
2, Full range Universal AC input 90-240V(81-267V AC max.)
3, No load power consumption less 0.10W
4, With Full safety approvals for all the world use.
5, V0 level Anti Fire Material and Patent Private Mould Housing
6, Level SIX High efficiency
7, Short circuit,Over charge,Over load,over temperature, protections.
8, 3 year quality warrant
Specifications
| Model | ZF120A-0900200 |
| Mode | Constant voltage |
| Input | 100-240VAC(81-267V AC max.), 50/60Hz |
| Output | 9V 0.2A 1.8W |
| Energy efficiency | DOE VI |
| DC cord length | 1.2m/1.5m/1.8m, etc. |
| DC jack size | 5.5mm*2.5mm*12mm/5.5mm*2.1mm*12mm/3.5mm*1.35mm*12mm/4.0mm*1.7mm*12mm/2.5*0.7mm/5.5*1.0mm/4 pin, etc. |
| Dimension(L*W*H) | 58.4*48.1*23.5MM |
| AC cord length | 1.2m/1.5m/1.8m, etc. |
| AC plug | AU/BR/IN/US/EU/UK, etc. |
| Certifications | GS /DOE VI/UL / CE / TUV / FCC / KC / KCC / SAA / RoHS |
| Protections | Short circuit protection, over voltage protection, over current protection,drop resistance |
| Working environment | -10°C~+40.9°C 5%~90%RH |
| Storage environment | -20°C~+85.9°C 5%~95%RH |
| Cooling method | Natural cooling down |
| RoHS compliant | Yes |
| Warranty | 3 years |
| Application | Security cctv camera,Communication,Allicances,Modem,Router,Recliner massage chair,3D printer, Vending Machine,Water purifier,LED lighting, medical, audio, aptop, etc. |
Applications
CCTV; ,Car-carried Refrigerator; Access System;Electric Blanket;Household Appliances;LCD Display;Vacuum Cleaner,Mini Electronic Device,Balance Car,Centrifuge;Audio Amplifier; Smart Home; Camera Equipment; Video Product; Air Purifier;Video Game Products; Router;Household Electric Fan; Massage Chair; LED strip;POS Machine; Security Surveillance System;Motor; Audio Transmitter; Audio Converter; IT Products; Digital Image; Wearable Electronics; LED light; Car Starter;Pump; Nebulizer; Air Cleaner;Communication Power Supply; Visual Intercom; 3D printer; POE Server;LED Lighting,CCTV camera,Monitor,Printer,Door Systerm,Small Household Appliance,LED Driver,Powerline Wifi,Massage Chair,Laptop,Air Purifier,Air Humidifier,Medical Machine,LCD,Mobile Phone,MP3/MP4,Stereo Audio,Credit card terminal.......
FAQ
- 1. How long is your product warranty?
- A: All of our products have 3 years warranty..
- 2. What's the advantage of your products?
- A: Over 10 years of experiences in ac dc power adapter production and sales,worldwide certificates,high-quality products,guaranteed after-sale services;
- 3. Are you accept OEM order?
- A: Yes, it's okay for us, please feel free to contact us;
- 4. What about delivery day?
- A: For sample with existing products, we can ship it right away,for customized one, need 2-5 days; and for customer order products in great quantity, 7 to 13 days. Generally 14-22 days for customer OEM products.
- 5. How about terms of payment?
- A: T/T, PayPal, Western Union, L/C,etc.
